Home > Products > High-quality spherical ceramic sand refractory particles | Refractory materials for high-temperature casting | Supplied by Zhengzhou Rongsheng

Particle shape
spherical
Main Ingredients
Mullite (Al2O3·2SiO2) Corundum (Al2O3) silicates
Aluminum content (Al2O3)
Approximately 45%-60%
Refractory
≥1800℃
Particle size
0.1-0.3mm 0.3-0.6mm 0.6-1.0mm 1.0-2.0mm 2.0-3.0mm
proportion
Approximately 2.6-3.2 g/cm³
Liquidity
Excellent, spherical particles ensure high flowability
thermal expansion rate
Low thermal expansion, approximately (3-5)×10^-6 /℃
Crushing strength
High, ensuring particle integrity during recycling.
Impurity content
≤0.5%
pH
6-8
Packing Specifications
25kg/bag 500kg/bag Bulk Customized Packaging
Application
Aluminum alloy casting Ferroalloy casting Steel casting Copper alloy casting General Metal Casting
Storage conditions
Keep the environment dry and well-ventilated, and avoid moisture.
Customization
Particle size customization Customized packaging specifications fine-tuning of chemical composition Customization for special fire resistance requirements

Recommended Products

Product Introduction

Zhengzhou Rongsheng Refractory Materials Co., Ltd. independently develops spherical ceramic sand refractory particles, refined using a high-purity alumina and silicate composite process. These particles possess excellent thermal stability (withstanding 1800℃), low thermal expansion rate, and strong thermal shock resistance. Their unique spherical structure significantly improves fluidity and filling density, reduces binder usage, enhances mold permeability, and effectively reduces the risk of casting defects such as cracks and porosity. The product complies with ISO9001 quality management system standards and is widely used in precision casting in the steel, non-ferrous metals (aluminum, copper, magnesium alloys), and machinery manufacturing industries. It is an ideal environmentally friendly alternative to chromite sand and zircon sand. Rongsheng provides customized formulations and global technical support services to ensure export customers receive stable and reliable high-quality casting materials.

Advantages and features

1. The spherical structure improves flowability and filling efficiency, saving more than 20% of adhesive usage.
2. It has an extreme temperature resistance of up to 1800℃, strong thermal stability, and is suitable for high-temperature casting processes.
3. Low expansion rate and high permeability significantly reduce casting defects and improve yield.
4. It can replace imported zircon sand and ferrochrome sand, offering high cost-effectiveness and environmental compliance.
5. Supports customization of particle size and chemical composition according to customer needs to meet the requirements of different metal casting.

Application Scenario

Suitable for high-temperature metal casting industries such as steel, aluminum alloys, copper alloys, and magnesium alloys, especially suitable for applications requiring high precision and surface quality, such as automotive parts, mechanical components, and aerospace castings. Target customers include domestic and international foundries, mold manufacturers, industrial material traders, and engineering contractors, covering international markets in Europe, America, Southeast Asia, and the Middle East.

Product Parameters

Physical performance parameters

form: spherical
Main Ingredients: Mullite combined with corundum, alumina, and silicon dioxide
Fire resistance (maximum service temperature): 1800 ℃
Particle size range: Customized according to customer needs, common range 0.1-2.0 mm
Bulk density: 1.50 - 1.70 g/cm³
Particle size distribution: Uniform, meeting the requirements for foundry sand.
Liquidity: Excellent, high filling properties
Thermal expansion coefficient: Low, ensuring dimensional stability
Particle intensity: High strength, resistant to breakage, suitable for recycling
See more

Chemical performance parameters

Main chemical component content: Al2O3: 45%-55%, SiO2: 40%-50%
Free alkali content: < 0.5%
Impurity content: Low, meets environmental standards
pH: neutral to slightly alkaline

Process and application performance

Industry of use: Aluminum, iron, steel, copper and other alloy casting industries
Casting performance: Reduce binder usage to improve mold permeability and slump.
Thermal shock resistance: Excellent, reduces casting cracks and defects
Recycling performance: High number of cycles, low loss
Environmental characteristics: Reduce waste sand discharge and environmental pollution

Packaging and storage

Packing: Environmentally friendly paper bags or ton bags packaging
Storage conditions: Keep dry and well-ventilated to prevent moisture and clumping.
